Cisco Catalyst WS-C9407R Switch

Catalyst 9407R Switch:

Cisco Catalyst 9400 Series 7 slot chassis. This cisco switch sells in network equipment market. The Cisco Catalyst® 9400 Series switches are Cisco’s leading modular enterprise switching access platform built for security, IoT and cloud.

The platform provides unparalleled investment protection with a chassis architecture that is capable of supporting up to 9Tbps of system bandwidth and unmatched power delivery for high density IEEE 802.3BT (60W PoE).

The Cisco C9407R switch is one of Cisco’s top modular enterprise switches, part of the Catalyst 9000 switch family, and is used to manage hybrid spaces (cloud and conventional networks).

The Cisco C9407R switch, using the Catalyst 9400 SUP-2/2XL supervisor and various line cards, as well as utilizing various technologies, can provide high security to your network and help you manage the hybrid workflow of small and large organizations while reducing costs.

Benefit of catalyst 9400 switches:

Cisco IOS XE opens a completely new paradigm in network configuration, operation and monitoring through network automation. Cisco’s automation solution is open, standards-based and extensible across the entire lifecycle of a network device. Various mechanisms employed to bring about the ease of network automation are outlined below based.

• Simplified Campus Automation is designed to optimize the discovery and configuration of devices in your network with a more streamlined simple and easy-to-use automation tool. With features such as simplified discovery, IT can discover devices within the network within just a few steps. Also available is a more streamlined GUI that provides a better simplified view of switch configurations and software details on a port-by-port basis.
• Automated device provisioning: This is the ability to automate the process of upgrading software images and installing configuration files on Cisco Catalyst switches when they are being deployed in the network for the first time. Cisco provides both turnkey solutions like Plug and Play along with off-the- shelf tools like Zero Touch Provisioning and Pre-boot Execution Environment (PXE) that enable an effortless and automated deployment.
• API-driven configuration: A modern network switch like Cisco Catalyst 9400 Series switches support a wide range of automation features and provides robust open APIs over Network Configuration Protocol (NETCONF) and RESTconf using YANG data models for external tools, both off-the-shelf and custom- built, so you can automatically provision network resources.
• Granular visibility: Model-driven telemetry provides a mechanism to stream data from a switch to a destination. The data to be streamed is driven through subscription of a data set in a YANG model. The subscribed data set is streamed to the destination at a configured interval. Additionally, open Cisco IOS XE enables the push model, which provides near real-time monitoring of the network leading to quick detection and rectification of failure situations.

Supported Ports in Catalyst 9407R Switch:

The Cisco 9400 Series Switches support a variety of ports, including:

• 2 anti-blocking 100/40 Gigabit Ethernet ports;

• 4 anti-blocking 10/25 Gigabit Ethernet ports;

• 2 anti-blocking 25 Gigabit Ethernet ports;

• 2 anti-blocking 40 Gigabit Ethernet ports that can be converted to 8 anti-blocking 10 Gigabit SFP+ ports;

• 384 RJ-45 10/100/1000M ports;

• 392 1 Gigabit Ethernet SFP ports;

• 388 10GbE SFP+ ports (with the ability to use 4 uplink ports and 384 10GbE ports using additional line cards);

• 384 10G/5G mGig RJ-45 ports;

Chassis:

The Cisco 9400 Series switches use a variety of capabilities to support internal systems, processors, and ports. In general, we are faced with three chassis models in this series of Cisco switches:

• Cisco Catalyst C9404R chassis;
• Cisco Catalyst CC9407R chassis;
• Cisco Catalyst C9410R chassis;

Each of these chassis differs in terms of port support capabilities, slot cards, supervisor engine, PoE technology support, maximum bandwidth, and more.
