Network Switch:
Cisco Catalyst C8200-1N-4T Router:
Cisco Catalyst C8200-1N-4T Router has multi-layered security that supports cloud-based security services and SASE-compliant, flexibility and providing the best internal security services for use in offices and small and medium-sized companies. This product is available at an excellent price and optimal performance in the network equipment market.
This Cisco router is designed to provide Cisco IOS XE SD-WAN software and SD-WAN solution for small branches, which includes a wide range of interfaces compatible with the planned architecture such as WAN, LAN and Voice Module. This network router supports APIs to allow you to have precise planning.
The Cisco Catalyst C8200-1N-4T Router has an 8-core processor with the ability to create high-speed WAN connections, with a DRAM memory of 8 GB and SD-WAN throughput of 1 GB. C8200-1N-4T Router can be upgraded to 16 GB and 32 GB DRAM for higher scale and performance
This router uses IPsec VPN hardware accelerators to scale IPsec traffic, and its ports transfer data at Gigabit Ethernet speeds. Cisco vManage, Cisco DNA Center management, and Programmable APIs are supported by the Cisco C8200-1N-4T router.
Public features of the Cisco 8200 router:
The Cisco Catalyst 8200 routers are a platform that is suitable for the edge of the network in branches and organizations. These routers support advanced capabilities such as 5G, SASE, as well as capabilities that were available in previous generation firewalls, and create a wide area network based on SD-WAN.
The Cisco 8200 series routers are a replacement for the Cisco ISR1000 series routers. These routers can serve small to large branches by providing capabilities such as traditional WAN and Cisco SD-WAN.
Front Panel of Cisco Catalyst C8200-1N-4T Router:
- Status LEDs
- RJ45 port
- USB port
- Ethernet ports
- RJ45 console ports
- LTE Module
- USB/NVMe Storage
- NIM Module
- Security lock
Cisco C8200-1N-4T Router vs Cisco C8200L-1N-4T Router:
The Cisco Catalyst C8200L-1N-4T Router is suitable for small branches that have SASE and cloud-based security needs. This router has a 4-core processor with 4 GB of internal memory and supports 4 Ethernet WAN ports and requires an SD-WAN DNA Subscription license.
The Cisco Catalyst C8200-1N-4T Router is suitable for more advanced needs and this model has an 8-core processor with 8 GB of internal memory and 4 Ethernet WAN ports with a speed of 1 gigabit. The Cisco C8200-1N-4T router is used for small to medium branches that need criteria such as high density, scalability and greater service flexibility, and its required license is WAN DNA Subscription.
| Features | C8200L-1N-4T | C8200-1N-4T |
|---|---|---|
| SD-WAN IPsec throughput (1400 bytes) | Up to 500Mbps | Up to 1Gbps |
| SD-WAN IPsec throughput (IMIX*) | 400Mbps | 900Mbps |
| SD-WAN overlay tunnels scale | 1500 | 2500 |
| IPv4 forwarding throughput (1400 bytes) | Up to 3.8Gbps | Up to 3.8Gbps |
| IPsec throughput (1400 bytes) | Up to 500Mbps | Up to 1Gbps |
| Number of IPsec Static Virtual Tunnel Interface (SVTI) tunnels | 1500 | 2500 |
| Number of Access Control Lists (ACLs) per system | 4000 | 4000 |
| Number of IPv4 Access Control Entries (ACEs) per system | 72000 | 72000 |
| Number of IPv4 routes | 800,000 with default 4 GB, up to 4M with 32GB | 1.6M with default 8GB, up to 4M with 32GB |
| Number of IPv6 routes | 800,000with default 4GB, up to 4M with 32GB | 1.5M with default8GB, up to 4M with 32GB |
| Number of queues | 16000 | 16000 |
| Number of Network Address Translation (NAT) sessions | 600,000with default 4 ,up to 2M with32GB | 1.2M with default 8GB, up to 2M with 32GB |
| Number of firewall sessions | 512000 | 512000 |
| Number of Virtual Route Forwarding (VRF) instances | 2000 | 4000 |
| Description | C8200L 1RU w/1 NIM slot and 4x 1Gigabit Ethernet WAN ports | C8200 1RU w/1NIM slot and 4x1Gigabit Ethernet WAN ports |
| 1G port density | 4 | 4 |
| Slots | 1NIM | 1NIM |
| 1PIM | 1PIM | |
| DRAM | 4GB | 8GB |
Specification of Cisco Catalyst C8200-1N-4T Router:
- Intel ® x86 CPU
- 8GB DRAM memory, expandable to 16 and 32 GB.
- Flash memory: 8GB
- Power supply: AC power supply
- Module card: NIM
- Form factor: 1U
- Port type and number: 4 Gigabit Ethernet WAN ports
- IPv4 forwarding throughput: 3.8Gbps
- IPsec throughput: 1Gbps
- Rack mountable: Yes
- Dimensions: 4.39×43.81×29.97 cm
- Weight: 4.54 kg
- Input voltage: 90-264 VAC
- Operating temperature: 0 to 40 ° C
Other Recommended:
| ports |
4×1G Ethernet ports |
|---|---|
| RAM |
8 GB |
| Flash |
8 GB |
| Forwarding rate |
3.8 Gbps |
| Rackmount |
1RU |
| IPsec Throughput |
1Gbps |
| Operate system |
Cisco IOS XE |
| Firewall |
Yes |
| QoS |
Yes |
