Cisco Fiber Optic Module SFP-10G-LR

Details:

Shipping:

Express Shipping to UAE.

Ship worldwide with  DHL, FedEx, EMS, etc.

Guarantee of Authenticity

Cisco Fiber Optic Module SFP-10G-LR:

The Cisco fiber optic module SFP-10G-LR is a 10 Gigabit Ethernet Small Form-Factor Pluggable (SFP+) transceiver module designed for long-range fiber optic communication. It operates over single-mode fiber (SMF) using 1310 nm wavelength and typically supports distances up to 10 kilometers.

This module uses LC duplex connectors, complies with IEEE 802.3ae 10GBASE-LR standards, and is hot-swappable, making it easy to insert or remove without shutting down the device. It’s commonly used in data centers, enterprise networks, and service provider environments for high-speed backbone links.

This module designed by Cisco company and you can buy it in network equipment market with 1-year Atech warranty. If you want to know more about network module specially Cisco fiber optical module, you can contact us.

Cisco Fiber Optic Module SFP-10G-LR

Introducing Cisco Fiber Optic Module SFP-10G-LR:

The SFP-10G-LR is a high-performance 10GBASE-LR SFP+ optical transceiver designed for long-distance data transmission over single-mode fiber (SMF). It is widely used in data centers, enterprise networks, and telecom environments to provide reliable, high-speed connectivity for switches, routers, and network interface cards (NICs).

The SFP-10G-LR is an enhanced small form-factor pluggable (SFP+) optical transceiver designed for 10 Gigabit Ethernet applications. This Cisco module supports a data rate of 10 Gbps and complies with the IEEE 802.3ae 10GBASE-LR standard.

Operating at a wavelength of 1310 nm over single-mode fiber (SMF), it uses an LC duplex connector and can transmit data up to 10 km (6.2 miles). The module delivers a Tx power range of -8.2 dBm to 0.5 dBm and a receiver sensitivity of -14.4 dBm, while maintaining low power consumption (typically less than 1W). It functions within a temperature range of 0°C to 70°C and is hot-swappable, enabling easy installation without network downtime.

In terms of features, this module offers high-speed performance, supporting full-duplex 10 Gbps links for bandwidth-intensive applications. Its long-reach capability makes it suitable for inter-building or campus connections.

The hot-pluggable design simplifies maintenance and upgrades, while energy efficiency ensures suitability for large-scale deployments. It also guarantees interoperability with a wide range of network equipment and includes Digital Diagnostics Monitoring (DDM) for real-time tracking of key parameters like temperature, voltage, and optical power, ensuring optimal performance and proactive maintenance.



Applications of Cisco Fiber Optic Module SFP-10G-LR:

The SFP-10G-LR module is used in various high-speed networking applications that require reliable and long-distance connectivity. Its main applications include:

  • Data Center Interconnects: Connecting servers, storage systems, and switches over single-mode fiber within large data centers or between data centers.
  • Enterprise Networks: Providing high-speed backbone links for enterprise LANs, campus networks, and metropolitan area networks (MANs).
  • Telecommunications Networks: Used by service providers to deliver 10G Ethernet services over long-distance fiber infrastructure.
  • Switch-to-Switch Links: Enabling high-bandwidth connections between aggregation and core switches.
  • Storage Area Networks (SANs): Supporting fiber connectivity for storage systems where low latency and high throughput are critical.
  • Metro and Regional Networks: Suitable for point-to-point connections in metro Ethernet environments.



Specification features of Cisco SFP-10G-LR:

  • Form Factor: SFP+ (Enhanced Small Form-Factor Pluggable)
  • Data Rate: 10 Gbps (10 Gigabit Ethernet)
  • Standard Compliance: IEEE 802.3ae 10GBASE-LR
  • Wavelength: 1310 nm (Laser)
  • Fiber Type: Single-Mode Fiber (SMF)
  • Connector Type: LC Duplex
  • Transmission Distance: Up to 10 km (6.2 miles)
  • Tx Power: -8.2 dBm to 0.5 dBm
  • Rx Sensitivity: -14.4 dBm
  • Power Consumption: Typically < 1W
  • Operating Temperature: 0°C to 70°C (Commercial)
  • Hot-Swappable: Yes



Other Recommended:

Cisco Fiber Optic Module SFP-10G-LRM

Cisco Module GLC-T

Cable Type

SMF

Data Transfer Rate

10Gbps

Wavelength

1310nm

Maximum Distance

10km

Connector Type

LC Duplex

Monitoring system

DDM

Power Consumption

 Typically < 1W

Hot Swappable

Yes

Operating Temperature

0°C to 70°C
